high-speed 2D barcode scanner (Wired/ Wireless/ Bluetooth ) IBC-U39/ IBC-U39W/ IBC-U39WB

Product features:

• High-speed decoding and responsiveness
• Strong versatility: USB, USB-COM and other interfaces are provided
• Compact, lightweight, ergonomically designed and comfortable to the touch
• Support remote online upgrades

Excellent durability: IP54 dustproof and waterproof rating, while withstanding the impact of a 1.5-meter drop to the concrete floor

Technical parameters: IBC-U39/ IBC-U39W/ IBC-U39WB
Physical parameters
Scan mode	Key trigger/auto-sensing/continuous scanning
Communication interface	USB-HID keyboard/USB-COM virtual serial port/RS232 serial port (optional).
Interface type	USB TYPE-B
Prompt method	Buzzer, LED light
How to set it up	Scan the setting code manually in turn
Housing material	ABS+PC
Cable standard	Straight line 1.6m
Appearance dimensions	165mm×66mm×95mm (product); 195mm×105mm×80mm (Outer Packaging)
weight	178g (net weight); 297g (including packaging accessories).
Performance parameters
Sensors	400,000 CMOS
Discrimination rate	800*480
light source	White LED
Scan angle	± 60°, ± 60°, 360° (elevation, declination, turning angle).
Scan rate	30 frames per second
Field of view	48° (H) x 30° (V)
Printing contrast	Minimum 15%
Decoding types	1D: EAN- 13, EAN-8, UPC-A, UPC-E, Code 128, Code 39, Code93, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 11, CodaBar, MSI-Plessey, GS1 Databar(RSS), etc 2D: QR Code, Data Matrix, PDF417, Micro QR, Aztec, etc，supports scanning codes from mobile phone screens.
Minimum resolution	1D code 3MIL; QR code 5MIL
depth of view	QR (10k) QR payment code (mobile code) Data Matrix （10mil） PDF 417 (6.7k) EAN-13 (13.3k) Code 39 （8.3mil）	10~140mm 60~600mm 10- 120mm 25- 140mm 30~330mm 30~240mm
Electrical parameters
Input voltage	DC 5V±10%
current	Working: 350 mAh; Standby: 130 mAh
Environmental parameters
Temperature	-10°C~50°C (operating); -40°C~+60°C (storage).
Humidity	5%-95% non-condensation
Ambient brightness	Max.5,000 Lux (fluorescent)
Seismic resistance	It can withstand a drop from the air up to 1.5m
