High Resolution Bar Code Reader QR Code Reader USB Wired Wireless Barcode Scanner Handheld 1D 2D

Product Description:

IBC-DS50 series CMOS barcode scanner is new appearance with fashion design. It is equipped with the advanced decoding algorithm, easy to read 1d and 2d codes. It supports many keyboard languages, no need driver, compatible with major operating systems. Supports the reading of paper barcodes, LCD display barcodes, mobile phone screen barcodes, anti-color barcodes, and non-standard barcodes such as print distortion and wrinkle breakage.

Product Features:

• Appearance layered design, embellished with local highlights, creating a new aesthetic experience;
• The new button design with the high-rebound switch components, the handle perfectly fits the palms of different sizes;
• Equipped with the advanced decoding algorithm, easy to read barcode, qr code, DM, PDF417, etc;
• Support many keyboard languages, no need driver, just plug and play, compatible with major operating systems;
• Professional electrostatic protection and anti-interference design, can be used normally in complex electromagnetic environment;
• Large-capacity battery, can continue reading more than 80,000 codes;
• 2.4G wireless transmission, automatic frequency hopping and anti-interference, the effective transmission distance in open space can reach 100 meters;
• The rear end is designed with a USB receiver storage compartment, which can effectively prevent loss;
• Long depth of field, large field of view, easy to scan long-distance barcode, can read 13mil commodity barcodes at a distance of 450mm, and 3mil low-density barcode also have excellent reading effects.

Product Specification:

1D 2D Wired Handheld Barcode Scanner IBC-DS50:

Model No. IBC-DS50
Product Name 1D 2D Wired Handheld Barcode Scanner
Light Source LED White light
Aiming Light Green Dot
Image Sensor 1280*800 pixels
CPU 1.2G Dual core
Resolution(maximum) 4mils
Minimum Print Contrast 20% Reflection Difference
Image Field of View Horizontal: 50°; Vertical: 38°
Reading Angle Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°
Decoding Capability 1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.
Reading Indicators LED light&Buzzer(adjustable tone and volume)
Typical depth of Field
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)
3.34mil   CODE 39 :  60mm—160mm
3.34mil  EAN-13  : 90mm—150mm
5mil   CODE39  : 70mm—240mm
5mil   EAN-13  : 70mm—230mm
13mil  UPC-A  : 40mm—450mm
5mil   PDF417  : 65mm—210mm
5mil   QR   : 75mm—140mm
10mil  QR   : 45mm—290mm
10mil  DM   : 30mm—260mm
20mil  QR   : 20mm—480mm
20mil   QR   : 20mm—480mm
Electrical Parameter
Current Working current(Standard): < 280 mA ; Standby current(Standard): < 130 mA
Input Voltage 5 VDC (+/- 10%)/500mA
Environmental Parameter
ESD protection(Air discharge) 8 kV
Drop resistance Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.
Temperature Working: -10 to 50 °C
Storage/Transport: -20 to 65 °C
Humidity(non-condensing) 5 – 95%
Ambient light Indoor: 0 to 6,000 lux; Outdoor: 0 to 100,000 lux
Product Size 169*67.5*85.5mm
Interfaces RS-232; USB HID; USB COM; HID POS available as per customer’s needs
Transmission Support multi-language transmission, compatible with major operating systems, support the editing of barcode data.



 1D 2D Wireless Handheld Barcode Scanner IBC-DS50R:

Model No. IBC-DS50R
Product Name 1D 2D Wireless 2.4G Handheld Barcode Scanner
Performance Parameter
Light Source LED White light
Aiming Light Green Dot
Image Sensor 640*480 pixels
Resolution(maximum) 4mils
Minimum Print Contrast 20% Reflection Difference
Image Field of View Horizontal: 46.6°; Vertical: 38.2°
Reading Angle Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60°
Decoding Capability 1D: All standard 1D codes including GS1 DataBar™ linear code can be automatically distinguished and decoded.
2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code
Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417.
Reading Indicators LED light&Buzzer(adjustable tone and volume)
Typical depth of Field
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.)
3.34mil  CODE 128 :  10mm—60mm
5mil   CODE128 :  5mm—90mm
3.34mil  EAN-13 :  10mm—55mm
5mil   EAN-13  : 5mm—85mm
13.34mil  EAN-13  : 20mm—190mm
5mil   PDF417  : 5mm—75mm
10mil   PDF417  : 5mm—190mm
15mil   PDF417  : 10mm—200mm
10mil   DM   : 5mm—100mm
20mil   DM   : 5mm—210mm
Electrical Parameter
Current Working current(Standard): < 280 mA ; Standby current(Standard): < 130 mA
Input Voltage 5 VDC (+/- 10%)/500mA
Environmental Parameter
ESD protection(Air discharge) 8 kV
Drop resistance Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface.
Temperature Working: 0 to 40 °C
Storage/Transport: -40 to 70 °C
Humidity(non-condensing) 5 – 95%
Ambient light Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux
Cordless Parameter
Transmission distance 100m for 2.4G (in open space)
Communication mode Wireless real-time transmission/wired transmission/storage mode
Battery capacity 2000mAh
Continuous working time >12H
Charging time 4-5H
