High Efficient Omnidirectional USB Wired 1D 2D QR Code Reader Scanning Platform Desktop Barcode Scanner
High Efficient Omnidirectional USB Wired 1D 2D QR Code Reader Scanning Platform Desktop Barcode Scanner
- Most Competitive Price
We can custom logo ,label,box,etc as your requirements totally,just contact me for accurate price!
- Customized solutions
- Precision manufacturing.
- Affordable excellence, guaranteed.
- Quality products, worldwide delivery.
*Get A Free Quote With No Obligation
- One-Stop Services,Contact Us For Free Samples
- We Provide Global Delivery By Air/Sea/Train Shipping From Door To Door Or To Designated Port.
- 20+ Years Experienced Team To Offer Suitable Packaging Proposal
High Efficient Omnidirectional USB Wired 1D 2D QR Code Reader Scanning Platform Desktop Barcode Scanner
Product Description:
IBC-8280 is CMOS desktop barcode scanner. It is strong body with scratch-resistant material. Quickly read various LCD and OLED mobile phone screen codes and printed product codes. Using international advanced image transmission technology, with two-way communication instant error correction feedback, complete a variety of commonly used one-dimensional code and two-dimensional code reading. Supports the reading of paper barcodes, LCD display barcodes, mobile phone screen barcodes, anti-color barcodes, and non-standard barcodes such as print distortion and wrinkle breakage. with Powerful scanning function, it is Excellent at decoding colorful, distorted, poor printed, fuzzy barcodes. Auto-Sensing Scan, when the barcode is close, it will be automaticallyscanned by induction, without manual operation. Adjust the scanning window according to theneeds of the scanning scene. Compatible With Multiple operation system, USB interface is plug and play, no need to set upconvenient and fast. It is the best choice for you to improve your work efficiency. It is widely used in retail stores, supermarket, library, hospital, pharmacy and other industries.
Product Features:
• Stylish and compact, attractive.
• Automatic dormant mode, energy-saving.
• 300,000 pixels global shutter, with great speed and precision.
• Minimum resolution: 4 mils
• Bright White LED for illuminating scanning surfaces.
• Read all mainstream 1D&2D bar codes.
• Strong body with scratch-resistant material.
• Quickly read various LCD and OLED mobile phone screen codes and printed product codes.
Product Specification:
| Model No. | IBC-8280 |
| Product Name | 1D 2D Wired Desktop Barcode Scanner |
| Performance Parameter | |
| Light Source | LED White LED |
| Image sensor | 640*480 pixels Global Shutter |
| Resolution(maximum) | 4mil |
| Print contrast ratio(minimum) | 20% |
| Motion tolerance | 1.6M/sec |
| Reading Angle | Pitch: ±65°; Roll(Tilt): 0-360°; Skew (Yaw): ±60° |
| Image field of view | D50°/ H38° /V30° |
| Decoding Capability | 1D: All standard 1D codes, including GS1 DataBar™ linear code can be automatically distinguished and decoded. |
| 2D: Aztec Code; Data Matrix; MaxiCode; QRCode; HANXIN; MicroQR Code | |
| Stack code: GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar Composite; MicroPDF417; PDF417. | |
| Reading Indicators | LED/Buzzer(adjustable tone） |
| Typical depth of Field (The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
5mil CODE128: 0mm—70mm |
| 5mil EAN-13: 0mm—70mm | |
| 13.34mil EAN-13 : 0mm—240mm | |
| 5mil PDF417 : 0mm—60mm | |
| 10mil PDF417: 0mm—170mm | |
| 15mil PDF417 : 0mm—270mm | |
| 20mil DM : 0mm—80mm | |
| Physical characteristics | |
| Color available | White; Black |
| Dimensions（L*W*H） | 96*105.55*157.06mm |
| Weight | 278g |
| Cable | 1.8M |
| Electrical Parameter | |
| Current | Working current(Standard): < 300 mA Standby current(Standard): < 210 mA |
| Input Voltage | 5 VDC (+/-5%)/500mA |
| Environmental Parameter | |
| ESD protection | Contact discharge: 8 kV; Air discharge: 15kV |
| Drop resistance | Withstands repeated drops from 1.2m/4.0 ft onto a concrete surface. |
| Temperature | Operation: -20 to 40 °C |
| Storage/Transport: -40 to 70 °C | |
| Humidity(non-condensing) | 5 – 95% |
| Ambient light | 0 -100,000 lux |
| Interfaces | |
| Interfaces | USB HID; USB COM; RS-232; optional interface |
